| Light source | 19x40W Osram Ostar™ led RGBW Full Color CRI ≥ 83 Ra LED refresh frequency: adjustable from 900 Hz to 25 KHz. |
| Optic system | Projection angle: zoom from 5 ° to 50 ° Illuminance: 52400lux @5m (full ON – 5°) / 1900lux @5m (full ON – 50°) Lens type: honeycomb gapless plano-convex optics |
| Color system | LED source RGBW Full color Infinite chromatic possibilities Calibrated led sources |
| Effects | Electronic dimmer 0-100% Motorized zoom Electronic strobo, pulse, random, single pixel Single Pixel control Pre-programmed dynamic and static patterns with programmable fades Virtual colour wheels: foreground, background with programmable fades CCT control: +/- green correction |
| Control and programming | 7 DMX configurations available: 15/16/24/25/38/58/99 channels Protocols: DMX512, RDM, Art-Net, sACN , Kling-Net Optional wireless DMX receiver (order code SG WECONUSB) 8/16bit Pan & Tilt resolution Master/Slave mode Reset function via DMX 3 Custom Program modes with 5 scenes Virtual Colour Wheel with 62 colors White Presets with 10 macros Virtual linear color wheel from 2.700 K to 10.000K Customizable color calibration system 4 Dimmer curves: Linear, Square, I-Square, S-Curve 5 Dimmer mode: Standard, Stage, TV, Architectural, Theatre Flight Case mode to protect the zoom |
| Structure and cabinet | Aluminum internal structure with hi-resistance ABS cover High resolution LCD colour display with touch buttons Pan angle: 540°/630° Tilt angle: 270° Mounting points: 2 pairs of 1/4-turn locks omega older Automatic repositioning of Pan & Tilt Pan&Tilt movement lock system XLR 3 poles DMX IN/OUT connection RJ45 EtherCON data connectors IN/OUT USB port for software update and wireless DMX receiver IP rating: 20 Low-noise controlled cooling system Noise levels @1m: Fan AUTO 50dB(A), Fan HIGH 53dB(A), Fan LOW 40dB(A) Backup battery for user menu access without connecting to the main power |
| Power supply | Input Voltage: AC~100-240V, 50/60 Hz Output Voltage: AC~100-240V, 50/60 Hz – Max 5A Switching power supply unit Max power: 935W @ 230VAC Power connections: Seetronic X Series IP65 IN/OUT |
| Weight and dimensions | Net weight: 19 kg Dimensions (LxAxP): 388x469x260 mm |
