Halo Fresnel 200W 3200K

Theater projector Fresnel COB led 200W

Description

HALO LED is the result of a Sagitter project, which can replace the most common incandescent theatre projectors with a product featuring low power consumption and the same luminous efficiency of the most common incandescent sources. The combination of a cutting edge power supply system and a next generation 3200K white COB LED source, makes the projector suitable for stages of any size. The optical equipment capable of modifying its projection angle from 15° to 55° is entrusted to a high-precision electronic zoom, controlled both via DMX and from the control panel through dedicated control keys.

SG HALOFWW

Technical Specifications

Light source

  • 1X200W led COB Warm White 3200K
  • CRI ≥85Ra
  • LED lifespan: >50.000h
  • LED refresh frequency: >400Hz flicker-free

Optic system

  • Beam angle: zoom 15°-55°
  • Luminous flux: 2396 lux @5mt (15°)
  • Luminous flux: 1463 lux @5mt (55°)

Color system

  • LED source COB Warm White 3200K

Effects

  • Linear dimmer 0-100%
  • Strobe: electronic 1-20 flashes/s with adjustable speed
  • Control and programming
  • 2 different DMX channels configurations: 2/3 channels
  • Protocol USITT DMX 512
  • Manual mode for dimmer and zoom adjustment
  • Direct manual control for zoom on the rear panel

Structure and cabinet

  • Black aluminum housing
  • LCD blue graphic display
  • Mounting points: single bracket for suspension
  • Rotating barndoor with “safety cable” (included)
  • Single handle in the rear side for easy transportation
  • 3/5-poles XLR in/out connection
  • IP rating: IP 20
  • Forced air cooling system “low noise” with fans for high efficiency and very low noise

Power supply

  • Input Voltage: AC~100-240V 50/60Hz
  • Switching power supply unit
  • Power consumption 250W
  • IN / OUT power connection with powercon sockets
  • Power supply cable 1,5 mt included
  • Max 4 pcs linkable @240V

Weight and dimensions

  • Net Weight: 8,4 kg
  • Dimensions:  260x450x310 mm
