| Effects | Single pixel control |
| Control and programming | 2 different DMX configuration available 7/150 Protocols: Art-Net, sACN, RDM UCS8903 16-bit color data led pixel protocol |
| Structure and cabinet | Black metal housing Mounting points: 19” / 1 U rack mount RJ45 EtherCON data connectors IN/OUT 2 outputs Seetronic 4pin XLR IP65 (Max 8pcs STARPIX BAR each) Seetronic X Series IP65 Power Connectors IN/OUT IP rating: IP20 |
| Power supply | Input Voltage: AC~100-240V, 50/60 Hz Switching power supply unit Max power: 320W @ 230VAC Power connections: Seetronic X Series IP65 IN/OUT Power supply cable 1 mt included |
| Weight and dimensions | Net weight: 3 kg Dimensions: 482x200x44 mm |
| Effects | Single pixel control |
| Control and programming | 2 different DMX configuration available 7/150 Protocols: Art-Net, sACN, RDM UCS8903 16-bit color data led pixel protocol |
| Structure and cabinet | Black metal housing Mounting points: 19” / 1 U rack mount RJ45 EtherCON data connectors IN/OUT 2 outputs Seetronic 4pin XLR IP65 (Max 8pcs STARPIX BAR each) Seetronic X Series IP65 Power Connectors IN/OUT IP rating: IP20 |
| Power supply | Input Voltage: AC~100-240V, 50/60 Hz Switching power supply unit Max power: 320W @ 230VAC Power connections: Seetronic X Series IP65 IN/OUT Power supply cable 1 mt included |
| Weight and dimensions | Net weight: 3 kg Dimensions: 482x200x44 mm |
