• ARH 600 is the ideal solution for generating high density smoke, with a dedicated DMX software. The stability of emissionis one of its most important features, making it perfect for saturating small and medium-sized environments. This machinefeatures the most advanced technology that distinguish it from all other smoke machines available on the market. Itguarantees the production of pure, white and dry smoke, satisfying the needs of all professionals while consuming only300W. The electronic sensor for the liquid level in the tank disables the operation of the machine when the liquid level istoo low, thereby protecting the pump and the boiler. ARH 600 meets the transport needs of the rental and touring marketperfectly thanks to its compact iron structure equipped with a convenient case for transport (included).
ELECTRICAL DATA
Supply: AC~230V – 50Hz
Power consumption: 300W
CONTROL
Control software: LCD Display
Control: Manual mode, DMX
Electronic temperature control
Fan speed control
Continuos output
Channels DMX: 2 CH
TECHNICAL DATA
Tank: 1 l
Warm up time: 60 sec.
Power IN: VDE connectors
For best applications and correct function we recommend using Proel / Sagitter fluids
Weight: 19 kg
Dimensions: 380x260x470 mm
DMX connection: XLR 3 poles
• ARH 600 is the ideal solution for generating high density smoke, with a dedicated DMX software. The stability of emissionis one of its most important features, making it perfect for saturating small and medium-sized environments. This machinefeatures the most advanced technology that distinguish it from all other smoke machines available on the market. Itguarantees the production of pure, white and dry smoke, satisfying the needs of all professionals while consuming only300W. The electronic sensor for the liquid level in the tank disables the operation of the machine when the liquid level istoo low, thereby protecting the pump and the boiler. ARH 600 meets the transport needs of the rental and touring marketperfectly thanks to its compact iron structure equipped with a convenient case for transport (included).
ELECTRICAL DATA
Supply: AC~230V – 50Hz
Power consumption: 300W
CONTROL
Control software: LCD Display
Control: Manual mode, DMX
Electronic temperature control
Fan speed control
Continuos output
Channels DMX: 2 CH
TECHNICAL DATA
Tank: 1 l
Warm up time: 60 sec.
Power IN: VDE connectors
For best applications and correct function we recommend using Proel / Sagitter fluids
Weight: 19 kg
Dimensions: 380x260x470 mm
DMX connection: XLR 3 poles
