• SAGOLEDWWCW completes the innovative line of Profile Spot LED with the addition of the important colour temperaturecontrol, ranging from 3000°K to 6100°K, by using a powerful 170W LED source consisting of a special “array” of diodesdesigned to ensure uniformity of the white colour throughout the light beam. Thanks to its extreme luminous intensity,this projector is able to replace the normal Profile 575 with HPL lamp, offering a reduced weight thanks to a strong cabinetmade of black ABS plastic. The projector is compatible with all traditional optics for Profile 13° (included) 19° – 26° – 30°(optional) gobos (included) and Iris (optional) holders
ELECTRICAL DATA
Supply: AC~100-240V, 50/60Hz
Power consumption: 200W
LIGHT SOURCE
LED: leds array 170W (3.000°K – 6100° K)
Lux@5m: 6.640 LUX
Beam: 13° included (19°-26°-30° on request)
CONTROL
Control software: LCD Display
Control: auto mode, DMX mode, master/slave mode
Channels DMX: 3 CH
Color Temperature: change control
TECHNICAL DATA
Chassis: high resistance polymer
Anchorage: Single bracket for anchoring
Power IN: POWERCON connector
Weight: 6,4 kg
Dimensions: 695x305x300 mm
DMX connection: XLR 3 poles
Cooling: forced air with electronically controlled fans
IP rating: IP20
